Description Smart Lithium Battery PRO 12V 100A Smart Lihtium Iron Phosphate Battery w/Self-Heating Bluetooth (5000 Cycles) RENOGY Smart Lithium Battery Iron Phosphate with self heating plus bluetooth for easy monortoring run your camp lights even use an Induction cooker, your coffee macine your tv, with a Renogy 3000 watt inverter, charge it with power from the sun solar power can charge with 240 volt can charge with your alternator from your vehicle Delivers up to 6% more power than rated capacity for optimized performance. Provides 300A for 10 seconds, starting heavy loads efficiently. Supports series, parallel, or both connections for flexibility. Equipped with a 100A BMS and low-temp cut-off for superior safety. Includes a 5-year warranty and 24-hour support for peace of mind. ELECTRICAL SPECIFICATIONS Battery Type: Lithium Iron Phosphate Rated Capacity: 100Ah Norminal Voltage: 12.8V Cycle Life (0.5C/1C, 25℃): 5000 Cycles (80% DOD, 80% EOL) CHARGING PARAMETERS Charge Voltage: 14.4V Maximum Charge Current: 100A Maximum Discharge Current: 100A Charge Temperature Range: 0°C to 55°C / 32°F to 131°F Discharge Temperature Range: -20°C to 60°C / -4°F to 140°F Connection Method: Series (Up to 4); Parallel (Up to 8); Series & Parallel (4P4S) Communication Protocol: N/A Recommended Terminal Torque: 10 N·m Protection Rating: IP65 Housing Material: ABS Terminal Bolt Size: M8 Dimensions: 260 x 169 x 211 mm / 10.24 x 6.65 x 8.31 inch Weight: 10.5 kg / 23.15 lbs opc: ACCESSORIES Long Terminal Bolts (2): M8 opc: CERTIFICATIONS MSDS, UN38.3, FCC , PSE, CE, UKCA, IEC62619: YES opc: WARRANTY Smart Lithium Battery Material and Workmanship Warranty: 5 Years Warranty Renogy 12V 100Ah Core Series LiFePO4 Battery 100Ah Core vs. Lead-acid Upgrade to lithium for next-level performance. 100Ah Core vs. Other LiFePO4 Unmatched performance for your most demanding energy needs Extra Juice. More Possibilities. The Renogy 12V 100Ah Core delivers more than expected. With a max. 6% extra capacity, you’ll be ready for unexpected storms, hurricanes, wildfires, and other challenges when you need it most. Powerful to the Core Providing consistent power that lasts nearly 10 times longer than a standard lead-acid battery, the Renogy 12V 100Ah Core LiFePO4 Battery uses EV-grade battery cells for long-lasting performance. Year-round Protections The built-in 100A battery management system (BMS) ensures peace of mind for year-round use. The low-temperature cut-off prevents charging when temperatures fall below 32°F, protecting your battery. Protections Against Bumps We know the road can be bumpy. That’s why the battery features a rugged structural design to keep components safe from impacts during your travels. Smart Lithium Battery Connect in Series Connect in Parallel Connect in Series-Parallel Extend Your Cabin Retreat Transform your cabin into a comfortable, off-grid retreat. By connecting 8 100Ah Core batteries in parallel, you can power your cabin for up to 4 days, even running air conditioning and refrigerators. Experience total convenience and relaxation in your off-grid haven. Power Your Journey Longer Whether you’re a weekend adventurer or a full-time nomad, Renogy Core 100Ah LiFePO4 batteries provide easy power access. Connecting 4 batteries in series extends your RV’s power supply, offering 2 days of off-grid energy for added comfort. Enhance Your Workshop Power Connect 16 100Ah Core batteries in series-parallel for your off-grid workshop, ensuring ample power for your tools. With up to 2.5 days of uninterrupted power, fuel your DIY projects without a hitch. Dimensional Reference Guide Before installation, ensure you leave 1.97-3.94 inches (5-10 cm) of clearance above the battery, and at least 7.87 inches (20 cm) on the side with busbars for proper installation. https://www.facebook.com/4wdlightsandcamping.com. https://4wdlightsandcamping.com.au/product/nomad-artic-fridge-freezer-95l/
