STGIPS20K60 – GIPS20K60 IGBT Module – 600V 17A Intelligent IGBT Power Module

STGIPS20K60 – GIPS20K60 IGBT Module – 600V 17A Intelligent IGBT Power Module The STGIPS20K60 is an intelligent power module provides a compact, high performance AC motor drive in a simple, rugged design. Combining ST proprietary control ICs with the most advanced short-circuitrugged IGBT system technology, this device is ideal for 3-phase inverters in applications such as home appliances and air conditioners. SLLIMM? is a trademark of STMicroelectronics. Applications Of STGIPS20K60 – GIPS20K60 IGBT Module – 600V 17A Intelligent IGBT Power Module: 3-phase inverters for motor drives  Home appliances, such as washing machines, refrigerators, air conditioners and sewing machine. Features of STGIPS20K60 – GIPS20K60 IGBT Module – 600V 17A Intelligent IGBT Power Module: IPM 18 A, 600 V 3-phase IGBT inverter bridge including control ICs for gate driving and freewheeling diodes  Short-circuit rugged IGBTs  VCE(sat) negative temperature coefficient  3.3 V, 5 V, 15 V CMOS/TTL input comparators with hysteresis and pull-down / pull-up resistors ? Under voltage lockout  Internal bootstrap diode  Interlocking function  Smart shutdown function  Comparator for fault protection against over temperature and overcurrent  DBC leading to low thermal resistance   Isolation rating of 2500 Vrms/min UL Recognized: UL1557 file E81734 SKU: RM001241 Category: IGBT Warehouse Code: R00008-S02-P06-Z01
